A new data-driven approach could help automated cars handle rural curves in ways that feel more natural to human passengers. Researchers in Germany have converted thousands of real-world cornering maneuvers into a catalog of likely driving trajectories, using spatial “keypoints,” machine-learning clustering, and graph theory to describe how vehicles enter, negotiate, and leave a bend. The method is designed to give automated lateral-control systems more than a single mathematically optimal path: it offers a menu of human-inspired alternatives that could eventually be selected according to road geometry, vehicle type, traffic, and passenger expectations.
The work addresses a major road-safety problem. Although most injury crashes occur in urban areas, rural roads are responsible for a disproportionate share of deaths. In the United States, rural roads accounted for 40% of all traffic fatalities in 2023, according to the National Highway Traffic Safety Administration (NHTSA), despite carrying only 19% of the population. The German researchers cite similar statistics from their own country: in 2024, country roads (excluding motorways) accounted for 23.69% of injury crashes but 56.71% of road fatalities. Leaving the road was the most common injury-crash category on these roads, representing 28.74% of cases. Curves are particularly demanding because the vehicle must continuously regulate its lateral position while speed, visibility, road curvature, and oncoming traffic change the driver’s available safety margin.
Advanced driver-assistance systems can reduce unintended lane departures, but their safety benefits depend on whether people are willing to leave them switched on. Steering that feels abrupt, overly cautious, or difficult to understand can make drivers uncomfortable. Previous research has shown that users often deactivate assistance functions that do not match their expectations. For highly automated driving at SAE Level 3 or above, this issue becomes more critical: the system, rather than the driver, is responsible for choosing and following a trajectory, so the vehicle’s behavior must be both technically safe and psychologically acceptable. A 2024 J.D. Power study found that 61% of drivers who turned off lane-keeping assistance did so because it felt “unnatural” or “jerky,” highlighting the real-world impact of trajectory design.
To learn how people actually drive curves, the team analyzed data from eight instrumented vehicles operated during a field campaign covering approximately 250,000 kilometers. The fleet included two Volkswagen Golf 7s, four Volkswagen Passat B8s, a Volkswagen Tiguan III, and a Volkswagen Atlas, providing a mixture of compact, midsize, and sport-utility vehicle geometries. The vehicles recorded data at 100 hertz from vehicle-dynamics sensors, steering and pedal inputs, GPS, radar, and a forward-facing camera. The campaign involved 128 participants aged 20 to 43, although the sample was predominantly male and therefore does not represent the entire driving population. Future work could expand to include a more diverse demographic.
The researchers focused on country-road curves with radii of 450, 600, and 900 meters, driven at speeds between 60 and 110 kilometers per hour. Curve radius is a measure of how sharply a road bends: a smaller radius means greater curvature and stronger steering demands. The team estimated radius from vehicle speed and yaw rate using the relationship ρ = v/|ψ̇|. The sign of yaw rate distinguished left-hand from right-hand bends. A detection algorithm then isolated sustained curves, rejecting short transients and complex combinations such as tightly connected S-bends. A candidate segment had to cover more than 150 meters and remain within 75 meters of its target radius.
Because the analysis depended on the vehicle’s position inside the lane, the researchers also developed a quality-control system for camera-based lane detection. The camera supplied distances to the left and right lane markings, but worn paint, missing markings, and sudden detection errors could create false lateral movements. When one boundary disappeared temporarily, the system estimated it using the recent average lane width, provided the remaining boundary was detected with high confidence. The vehicle’s lateral deviation was then calculated relative to the lane center and normalized by lane width, allowing trajectories from roads with different physical dimensions to be compared. Only curve segments with a lane-quality score of at least 0.8 were retained, meaning that reliable lane information was available for at least 80% of the maneuver.
More than 2,800 valid curve segments survived the filtering process. Each curve was reduced to three spatial keypoints: the entry, the apex, and the exit. The apex is the central portion of the bend, where the vehicle is typically most deeply engaged with the curve. At each keypoint, the team measured normalized lateral deviation, which indicates whether the car was positioned toward the center, inner side, or outer side of the lane. This compression transformed every continuous maneuver into three representative observations while preserving the most important phases of cornering. The curves were also labeled according to direction and whether oncoming traffic was present, producing separate groups for left and right bends under traffic and free-driving conditions.
The researchers used the unsupervised machine-learning method k-means to identify three characteristic lateral positions at each keypoint. K-means groups observations by minimizing the squared distance between individual measurements and their assigned cluster center. An elbow analysis showed that the improvement in fit was substantial up to three clusters but became much smaller when additional clusters were added. The resulting groups broadly represented near-center driving, moderate lateral bias, and stronger movement toward the inner or outer edge. In one example involving a 450-meter left curve without oncoming traffic, the inner-biased group at the apex corresponded to drivers cutting the corner slightly, while the outer-biased group reflected a wider entry.
The next step involved building a graph-based representation. Each keypoint cluster was treated as a node, and the transitions between entry, apex, and exit were encoded as edges. This allowed the team to model the entire cornering maneuver as a path through a graph, capturing the most common sequences of lateral positions. For example, a typical “smooth” trajectory might start near the center, move slightly inward at the apex, and return to center at the exit. The graph also captured less common but still viable patterns, such as staying wide throughout the curve. By associating probabilities with each edge, the researchers created a probabilistic model of human cornering behavior.
This approach offers several advantages over traditional trajectory planning. Rather than optimizing a single path based on vehicle dynamics and road boundaries, the system can select from a set of human-like alternatives. The graph can be updated with new data, making it adaptive to different driving styles and regional differences. Moreover, the method is computationally lightweight, requiring only three keypoints per curve, which could allow real-time implementation on embedded hardware.
The researchers acknowledge limitations. The data came from a single country and a predominantly male driver sample. The curves studied were limited to moderate radii (450–900 m), and the method has not yet been tested on tighter bends or complex road geometries like roundabouts. Additionally, the lane-quality filter removed many segments, potentially biasing the dataset toward well-marked roads. Future work should include more diverse road types, drivers, and environmental conditions, as well as subjective validation with passengers to confirm that the selected trajectories feel natural.
Despite these caveats, the study represents a significant step toward making automated driving more acceptable. By encoding human-like cornering strategies, engineers can give autonomous systems a behavioral repertoire that matches what real drivers do—and what passengers expect. For the U.S. market,
